T1D210 – Rockford Fosgate – Power 10″ T1 2-Ohm DVC Subwoofer

R10,014.81 inc. VAT

In stock

Description

The Power Series T1D210 Dual 2-Ohm subwoofer builds on innovative new Rockford Fosgate technologies. These bad boys have patented VAST technology that increases surface cone area up to 25% so the T1D210 performs like a much larger woofer over the previous model. The new FlexFit basket not only looks the part but it provides extreme flexibility for extreme installations. Clean, high tech and ready to set off car alarms, the T1D210 is here!

  • Symmetrical dual progressive roll tear resistant poly-cotton spiders
  • Periodic-stitched fatigue resistant tinsel lead wire
  • Proprietary 8 AWG insulated allmetal input spring terminal connection
  • High-temp voice coil with spun-laced Nomex® re-inforcement collar
  • Optimized and matched magnetic and complicance geometry
  • Anodized aluminum heat sinking dust cap
  • Kevlar fiber reinforced paper cone
  • Rigid die-cast aluminum basket
  • Optimized pole piece and spider venting
  • Anodized aluminum voice coil former / copper clad aluminum wire
  • 1 Year Warranty

Additional information

Weight 11.65 kg
Dimensions 34 × 32 × 32 cm
Brand

Product Type

Good, Better, Best

Power Rating

Size

Nominal Impedance

Subwoofer Depth

Overview

The Power Series T1D210 Dual 2-Ohm subwoofer builds on innovative new Rockford Fosgate technologies. These bad boys have patented VAST technology that increases surface cone area up to 25% so the T1D210 performs like a much larger woofer over the previous model. The new FlexFit basket not only looks the part but it provides extreme flexibility for extreme installations. Clean, high tech and ready to set off car alarms, the T1D210 is here!

FEATURES AT A GLANCE

  • Symmetrical dual progressive roll tear resistant poly-cotton spiders
  • Optimized and matched magnetic and complicance geometry
  • Proprietary 8 AWG insulated allmetal input spring terminal connection
  • Anodized aluminum heat sinking dust cap
  • Kevlar fiber reinforced paper cone
  • Periodic-stitched fatigue resistant tinsel lead wire
  • High-temp voice coil with spun-laced Nomex® re-inforcement collar
  • Anodized aluminum voice coil former / copper clad aluminum wire
  • Optimized pole piece and spider venting
  • Rigid die-cast aluminum basket
  • 1 Year Warranty

Specification

Power Handling (Watts RMS)
600 Watts RMS
1200 Watts Max
Size
10″
Speaker Connector
Compression Terminal
Nominal Impedance
Dual 2-Ohm
Voice Coil Diameter
3″ (75.5 mm)
Mounting Depth
6.375 in. (161.9 mm)
Shipping Weight
25.7 Lbs. (11.65 Kg.)
SPL (dB @ 1w/1m)
83
Vas (Liters)
15.4
Re (Ohms)
3.25
Le (mH)
1.8
Fs (Hz)
34.5
Magnet Weight (oz)
100 oz. (2.84 kg)
Qts
0.54
Qes
0.59
Qms
6.00
Xmax (mm)
16
Cutout Diameter
9.0625 in. (230 mm)
Woofer Displacement
0.078 cu. ft. (2.2 Liters)
Sd (cm2)
345
CEA-2031 Compliant
CEA-2031 Guidelines
Subwoofer Type
Standard
Voice Coil Type
Dual Voice Coil
Sealed Box Volume (Vb)
0.75 cu. ft. (21.2 Liters)
Vented Box Volume (Vb)
1.5 cu. ft. (42.4 Liters)

Videos

Owners Manual

T1D210.pdf Owners Manual
