T500-1BDCP – Rockford Fosgate – Power 500 Watt Class-bd Constant Power Amplifier

T500-1BDCP – Rockford Fosgate – Power 500 Watt Class-bd Constant Power Amplifier

R12,695.00 inc. VAT

In stock

SKU: T500-1BDCP Categories: , , , Tag:

Description

The T500-1bdCP is based on the legendary T500-1bd amplifier design with a proprietary “Constant Power” configuration delivering up to 25% more power (Watts) across all impedance loads. The listening experience is cleaner, louder and more impressive than ever before. With the T500-1bdCP, you can now use an “under-the-seat” dedicated subwoofer amplifier to drive two 4-Ohm DVC subwoofers. This amp will provide enough bass to separate you from those envious car audio geeks.

  • 24dB/octave crossover
  • MOSFET power supply
  • MOSFET output stage
  • 4 Gauge power/ground connectors
  • Audiophile grade speaker connections
  • RCA pass-thru outputs
  • Infrasonic filter
  • 2-Year Warranty

Additional information

Weight 6.07 kg
Dimensions 29 × 21 × 5.5 cm
Brand

Product Type

Good, Better, Best

Channels

Power Rating

Circuit Topology Class

Power Wire Gauge

Overview

The T500-1bdCP is based on the legendary T500-1bd amplifier design with a proprietary “Constant Power” configuration delivering up to 25% more power (Watts) across all impedance loads. The listening experience is cleaner, louder and more impressive than ever before. With the T500-1bdCP, you can now use an “under-the-seat” dedicated subwoofer amplifier to drive two 4-Ohm DVC subwoofers. This amp will provide enough bass to separate you from those envious car audio geeks.

FEATURES AT A GLANCE

  • MOSFET output stage
  • Audiophile grade speaker connections
  • 4 Gauge power/ground connectors
  • 24dB/octave crossover
  • RCA pass-thru outputs
  • MOSFET power supply
  • Infrasonic filter
  • 2-Year Warranty

Specification

Cta-2006 Compliant
Number of Channels
1
Total Power
(Sum of Rated Power)
500 Watts RMS
Rated Power
(RMS Continuous Power)
300 Watts x 1 @ 4-Ohm
500 Watts x 1 @ 2-Ohm
500 Watts x 1 @ 1-Ohm
Dynamic Power
(PVC/PowerCube®)
328 Watts x 1 @ 4-Ohms
537 Watts x 1 @ 2-Ohms
707 Watts x 1 @ 1-Ohm
Bridgeable
No
Frequency Response
20Hz to 250Hz +/- 0.5dB
Input Sensitivity
150 mV to 4 V
Circuit Topology Class
Class BD
Efficiency (average)
86.2% @ 4-Ohm
82.3% @ 2-Ohm
73.4% @ 1-Ohm
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
1-Ohm: <1.0%
Signal Input
Low level: 1 RCA pair
Signal Output
Low Level: 1 RCA pair
Tone Controls
Bass: 0dB to +18dB @ 45Hz
Crossover Controls
Low-Pass (LP): 35-250Hz 24dB/Octave Butterworth
Infrasonic Filter: -3dB @ 28Hz 12dB/Octave
Remote Controls
Optional Remote Punch Bass EQ
(overrides built-in Punch Bass EQ)
Visual Indicators
Power
Thermal
Protect
Power Wire Gauge
4 AWG
Power Input Connector
Block
Speaker Wire Gauge
8 AWG to 18 AWG
Speaker Output Connector
Screw terminal barrier strip
Cooling
Convection
Heatsink
Operating Voltage
9 – 16 VDC
Recommended Fuse
(not included)
80 A
Average Current Draw (13.8V Music)
35 A
Max. Current Draw (13.8V Sinewave)
70 A
Suggested Alternator
75 A
Included In The Box
Dimensions (H x W x D)
2.14 x 8.14 x 11.41 (in)
5.42 x 20.68 x 28.97 (cm)
