T2500-1BDCP – Rockford Fosgate – Power 2500 Watt Class-bd Constant Power Amplifier

T2500-1BDCP – Rockford Fosgate – Power 2500 Watt Class-bd Constant Power Amplifier

R38,504.07 inc. VAT

ETA End May 2023 – Price Subject to Change – Amp can be flown into the County if needed Urgently! T&C’s will Apply!

In stock

SKU: T2500-1BDCP Categories: , , , Tag:

Description

The T2500-1bdCP is based on the legendary T2500-1bd amplifier design with a proprietary “Constant Power” configuration that delivers up to 25% more power (Watts) across all impedance loads. The result is a listening experience cleaner, louder and more impressive than ever before. This T2500-1bdCP amplifier pumps out 2,500 watts, easily driving any array of woofers wired to a 1-ohm load. Use two amps in Power-Sync mode for a whopping 5,000 watt power horse!

  • 24dB/octave crossover
  • 1/0 AWG power/ground connectors
  • Audiophile grade speaker connections
  • Infrasonic filter
  • MOSFET power supply
  • MOSFET output stage
  • RCA pass-thru outputs
  • PowerSync – allows 2 amplifiers to be “strapped” together
  • MasterSync – allows 1 amplifier to control an array of amplifiers
  • 0°/180° Phase Switch
  • Blue L.E.D. Simulated VU Signal/Power Meters
  • 2-Year Warranty

Additional information

Weight 10 kg
Dimensions 56 × 21 × 6 cm
Brand

Product Type

Good, Better, Best

Channels

Power Rating

Circuit Topology Class

Power Wire Gauge

Overview

The T2500-1bdCP is based on the legendary T2500-1bd amplifier design with a proprietary “Constant Power” configuration that delivers up to 25% more power (Watts) across all impedance loads. The result is a listening experience cleaner, louder and more impressive than ever before. This T2500-1bdCP amplifier pumps out 2,500 watts, easily driving any array of woofers wired to a 1-ohm load. Use two amps in Power-Sync mode for a whopping 5,000 watt power horse!

FEATURES AT A GLANCE

  • MOSFET power supply
  • Audiophile grade speaker connections
  • 24dB/octave crossover
  • 1/0 AWG power/ground connectors
  • RCA pass-thru outputs
  • Infrasonic filter
  • MOSFET output stage
  • PowerSync – allows 2 amplifiers to be “strapped” together
  • 0°/180° Phase Switch
  • Blue L.E.D. Simulated VU Signal/Power Meters
  • MasterSync – allows 1 amplifier to control an array of amplifiers
  • 2-Year Warranty

Specification

Cta-2006 Compliant
Number of Channels
1
Total Power
(Sum of Rated Power)
2500 Watts RMS
Rated Power
(RMS Continuous Power)
1500 Watts x 1 @ 4-Ohm
2500 Watts x 1 @ 2-Ohm
2500 Watts x 1 @ 1-OhmTwo amplifiers in bdSYNC:
5000 Watts x 1 @ 2-Ohm

Dynamic Power
(PVC/PowerCube®)
1823 Watts x 1 @ 4-Ohm
2940 Watts x 1 @ 2-Ohm
2980 Watts x 1 @ 1-Ohm
Bridgeable
Yes
(two amps can be “strapped” together using bd-Sync2 cable to create one monster amplifier)
Frequency Response
20Hz to 250Hz +/-0.5dB
Input Sensitivity
150 mV to 4 V
Circuit Topology Class
Class BD
Efficiency (average)
81.9% @ 4-Ohm
77.7% @ 2-Ohm
64.5% @ 1-Ohm
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
1-Ohm: <1.0%
Signal Input
1 RCA pair
Signal Output
1 RCA pair
Tone Controls
Bass: 0dB to +18dB @ 45Hz
Crossover Controls
Low-Pass (LP): 35Hz-250Hz @ 24dB/octave Butterworth
Infrasonic: 12dB/octave Butterworth, -3dB @ 28Hz
Remote Controls
Optional Remote PEQ
(overrides built-in Punch Bass)
Visual Indicators
Power (Blue LED)
Thermal (Red LED)
Protect (Yellow LED)
Output -00dB to +2dB @ 11 steps (Blue LEDs)
Battery 9VDC to 16VDC @ 11 steps (Blue LEDs)
Power Wire Gauge
1/0 AWG
Power Input Connector
Block
Speaker Wire Gauge
8 AWG to 16 AWG
Speaker Output Connector
Block
Cooling
Convection
Heatsink
Operating Voltage
9 – 16 VDC
Recommended Fuse
(not included)
300 A
Average Current Draw (13.8V Music)
175 A
Max. Current Draw (13.8V Sinewave)
350 A
Suggested Alternator
200 A
Included In The Box
Dimensions (H x W x D)
2.14 x 8.14 x 21.875 (in)
5.44 x 20.68 x 55.66 (cm)

Videos

Owners Manual

T2500-1BDCP
