R2-750X1 – Rockford Fosgate – Prime 750 Watt Mono Amplifier

R7,760.00 inc. VAT

In stock

Description

The Prime Series were developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. The latest generation of Prime Series amplifiers are also designed to be easy to setup and configure, making them perfect for use with factory audio or custom aftermarket systems.

  • Balanced Differential Inputs with RCA Pass Through Outputs
  • High Level Input Capable
  • Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
  • Features C.L.E.A.N. Set-up
  • Variable Input Gain adjustment level
  • Includes RLC Remote Level Control
  • Variable Infrasonic Filter
  • Continuously Variable On Board Punch EQ
  • Top Mounted Control Panel
  • Short Circuit & Over Current Protection
  • CEA-2006 Compliant & CE Compliant
  • Cast aluminum heat sink
  • Full Range Class D
  • Rollback Protection
  • Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
  • 1 Year Warranty

Additional information

Weight 3.05 kg
Dimensions 32 × 24 × 10 cm
Brand

Product Type

Good, Better, Best

Channels

Power Rating

Circuit Topology Class

Power Wire Gauge

Overview

The Prime Series were developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. These 3rd generation of Prime Series amplifiers are refined with the latest Rockford Fosgate technology for easy setup and configuration, making them perfect for use with factory audio or custom aftermarket systems.

FEATURES AT A GLANCE

  • Variable Input Gain adjustment level
  • High Level Input Capable
  • Balanced Differential Inputs with RCA Pass Through Outputs
  • Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
  • Includes RLC Remote Level Control
  • Top Mounted Control Panel
  • Features C.L.E.A.N. Set-up
  • Variable Infrasonic Filter
  • Short Circuit & Over Current Protection
  • Cast aluminum heat sink
  • Continuously Variable On Board Punch EQ
  • Rollback Protection
  • CEA-2006 Compliant & CE Compliant
  • Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
  • Class-D Topology
  • 1 Year Warranty

Videos

Specification

Cta-2006 Compliant
Number of Channels
1
Total Power
(Sum of Rated Power)
750 Watts
Rated Power
(RMS Continuous Power)
250 Watts x 1 @ 4Ω
500 Watts x 1 @ 2Ω
750 Watts x 1 @ 1Ω
Dynamic Power
(PVC/PowerCube®)
300 Watts x 1 @ 4Ω
545 Watts x 1 @ 2Ω
830 Watts x 1 @ 1Ω
Bridgeable
No
Frequency Response
20 Hz – 250 Hz
Input Sensitivity
Low-Level: 150 mV – 4 V
High-Level: 450 mV – 12 V
Circuit Topology Class
Class-D
Efficiency (average)
Total Harmonic Distortion (THD+Noise)
4Ω: <1.0%
2Ω: <1.0%
1Ω: <1.0%
Signal Input
Low-Level: 2 RCA
High-Level: 4-Pin Molex
Signal Output
Low-Level: 2 RCA
(Pass-Thru active with RCA or Hi-Level input)
Tone Controls
0 to +18 dB @ 45 Hz
Crossover Controls
Low-Pass:
50 Hz – 250 Hz @ 12dB/Octave ButterworthInfrasonic:
15 Hz – 40 Hz @ 12dB/Octave Butterworth

Remote Controls
Yes
Visual Indicators
Power/Protect
C.L.E.A.N. In
C.L.E.A.N. Out
Power Wire Gauge
4 AWG
Power Input Connector
Compression Terminal Block
Speaker Wire Gauge
8 AWG
Speaker Output Connector
Compression Terminal Block
Cooling
Convection
Heatsink
Operating Voltage
9 – 16 VDC
Recommended Fuse
(not included)
120 A
Average Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)
71 A
Suggested Alternator
Included In The Box
Dimensions (H x W x D)
1.9″ x 6.8″ x 10.1″
(4.9 cm x 17.3 cm x 25.5 cm)

Owners Manual

R2-750X1
