R2-300X4 – Rockford Fosgate – Prime 300 Watt 4-Channel Amplifier

R2-300X4 – Rockford Fosgate – Prime 300 Watt 4-Channel Amplifier

R6,515.00 inc. VAT

In stock

SKU: R2-300X4 Categories: , , , Tags: , ,

Description

The Prime Series were developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. The latest generation of Prime Series amplifiers are also designed to be easy to setup and configure, making them perfect for use with factory audio or custom aftermarket systems.

  • Balanced Differential Inputs with RCA Pass Through Outputs
  • High Level Input Capable
  • Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
  • Features C.L.E.A.N. Set-up
  • 2/4 Channel Input Selection Switch
  • Front and Rear Variable Input Gain adjustment level
  • Top Mounted Control Panel
  • Short Circuit & Over Current Protection
  • CEA-2006 Compliant & CE Compliant
  • Cast aluminum heat sink
  • Full Range Class D
  • Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
  • 1 Year Warranty

Additional information

Weight 2.59 kg
Dimensions 25.5 × 17.3 × 4.9 cm
Brand

Product Type

Good, Better, Best

Channels

Power Rating

Circuit Topology Class

Power Wire Gauge

Overview

The R2 models are developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. These 3rd generation of Prime Series amplifiers are refined with the latest Rockford Fosgate technology for easy setup and configuration, making them perfect for use with factory audio or custom aftermarket systems.



FEATURES AT A GLANCE

  • High Level Input Capable
  • 2/4 Channel Input Selection Switch
  • Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
  • Balanced Differential Inputs with RCA Pass Through Outputs
  • Features C.L.E.A.N. Set-up
  • Short Circuit & Over Current Protection
  • Front and Rear Variable Input Gain adjustment level
  • Top Mounted Control Panel
  • CEA-2006 Compliant & CE Compliant
  • Full Range Class-D
  • Cast aluminum heat sink
  • 1 Year Warranty
  • Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers

Videos



Specification

Cta-2006 Compliant
Number of Channels
4
Total Power
(Sum of Rated Power)
300 Watts
Rated Power
(RMS Continuous Power)
50 Watts x 4 @ 4Ω
75 Watts x 4 @ 2Ω
150 Watts x 2 @ 4Ω Bridged/Mono
Dynamic Power
(PVC/PowerCube®)
70 Watts x 4 @ 4Ω
115 Watts x 4 @ 2Ω
230 Watts x 2 @ 4Ω Bridged/Mono
Bridgeable
Yes
Frequency Response
20 Hz – 20 kHz
Input Sensitivity
Low-Level: 150 mV – 4 V
High-Level: 450 mV – 12 V
Circuit Topology Class
Class-D
Efficiency (average)
Total Harmonic Distortion (THD+Noise)
4Ω: <1.0%
2Ω: <1.0%
Signal Input
Front Low-Level: 4 RCA
Front High-Level: 4-Pin Molex
Rear Low-Level: 4 RCA
Rear High-Level: 4-Pin MolexInput Switch: 2/4 Input
(works for RCA/hi-level inputs)
Signal Output
Low-Level: 2 RCA
(Pass-Thru active with RCA or Hi-Level input)
Tone Controls
No
Crossover Controls
Front High-Pass:
50 Hz – 250 Hz @ 12dB/Octave ButterworthFront Low-Pass:
50 Hz – 250 Hz @ 12dB/Octave ButterworthRear High-Pass:
50 Hz – 250 Hz @ 12dB/Octave ButterworthRear Low-Pass:
50 Hz – 250 Hz @ 12dB/Octave ButterworthAll-Pass: Yes
Remote Controls
No
Visual Indicators
Power/Protect
C.L.E.A.N. In
C.L.E.A.N. Out (front)
C.L.E.A.N. Out (rear)
Power Wire Gauge
4 AWG
Power Input Connector
Compression Terminal Block
Speaker Wire Gauge
8 AWG
Speaker Output Connector
Compression Terminal Block
Cooling
Convection
Heatsink
Operating Voltage
9 – 16 VDC
Recommended Fuse
(not included)
60 A
Average Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)
39 A
Suggested Alternator
Included In The Box
Dimensions (H x W x D)
1.9″ x 6.8″ x 10.1″
(4.9 cm x 17.3 cm x 25.5 cm)

Owners Manual

R2-300X4
