R2-1200X1 – Rockford Fosgate – Prime 1200 Watt Mono Amplifier

R10,090.00 inc. VAT

In stock

Description

Primed for Performance, the R2-1200X1 amplifier is a 1200-watt, class-D, capable of operating at 4Ω, 2Ω or 1Ω mono. This amplifier is extremely efficient because of its class D technology which reduces demand on the vehicles electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. Supply that generates more power as voltage increases, and integrated Punch EQ that corrects for acoustic deficiencies while delivering up to 3X the bass. For subwoofers, a variable infrasonic filter and remote level control allows you to tune the bass for the desired level for the music.

Additional information

Weight 3.5 kg
Dimensions 36 × 24 × 10 cm
Brand

Product Type

Good, Better, Best

Channels

Power Rating

Circuit Topology Class

Power Wire Gauge

Overview

The R2 models are developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. These 3rd generation of Prime Series amplifiers are refined with the latest Rockford Fosgate technology for easy setup and configuration, making them perfect for use with factory audio or custom aftermarket systems.

FEATURES AT A GLANCE

  • Balanced Differential Inputs with RCA Pass Through Outputs
  • Variable Input Gain adjustment level
  • Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
  • High Level Input Capable
  • Features C.L.E.A.N. Set-up
  • Includes RLC Remote Level Control
  • Top Mounted Control Panel
  • Variable Infrasonic Filter
  • Continuously Variable On Board Punch EQ
  • Short Circuit & Over Current Protection
  • Cast aluminum heat sink
  • CEA-2006 Compliant & CE Compliant
  • Class-D Topology
  • Rollback Protection
  • Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
  • 1 Year Warranty

Specifications

Cta-2006 Compliant
Number of Channels
1
Total Power
(Sum of Rated Power)
1200 Watts
Rated Power
(RMS Continuous Power)
400 Watts x 1 @ 4Ω
800 Watts x 1 @ 2Ω
1200 Watts x 1 @ 1Ω
Dynamic Power
(PVC/PowerCube®)
489 Watts x 1 @ 4Ω
889 Watts x 1 @ 2Ω
1389 Watts x 1 @ 1Ω
Bridgeable
No
Frequency Response
20 Hz – 250 Hz
Input Sensitivity
Low-Level: 150 mV – 4 V
High-Level: 450 mV – 12 V
Circuit Topology Class
Class-D
Efficiency (average)
> 80%
Total Harmonic Distortion (THD+Noise)
4Ω: <1.0%
2Ω: <1.0%
1Ω: <1.0%
Signal Input
Low-Level: 2 RCA
High-Level: 4-Pin Molex
Signal Output
Low-Level: 2 RCA
(Pass-Thru active with RCA or Hi-Level input)
Tone Controls
0 to +18 dB @ 45 Hz
Crossover Controls
Low-Pass:
50 Hz – 250 Hz @ 12dB/Octave ButterworthInfrasonic:
15 Hz – 40 Hz @ 12dB/Octave Butterworth
Remote Controls
Yes
Visual Indicators
Power/Protect
C.L.E.A.N. In
C.L.E.A.N. Out
Power Wire Gauge
4 AWG
Power Input Connector
Compression Terminal Block
Speaker Wire Gauge
8 AWG
Speaker Output Connector
Compression Terminal Block
Cooling
Convection
Heatsink
Operating Voltage
9 – 16 VDC
Recommended Fuse
(not included)
200 A
Average Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)
121 A
Suggested Alternator
Included In The Box
Dimensions (H x W x D)
1.9″ x 6.8″ x 11.3″
(4.9 cm x 17.3 cm x 28.5 cm)

Videos

Owners Manuals

R2-1200X1

Extended Warranty

ARE YOU ENGINEERED TO ROCK?

Get a 1-Year extended amplifier warranty when using a matching Rockford Fosgate installation kit.

We want you to get the maximum performance and reliability from your Rockford Fosgate amplifier. We’re so certain using the right cables make a difference, we’ll give you and additional 1-Year amplifier warranty when using a matching installation kit!

  • 1 Purchase a Rockford Fosgate Punch or Power amplifier.
  • 2 Add the correct amplifier installation kit.
  • 3 Get an additional 1 year amplifier warranty FREE!

Click on the link below:

Rockford Fosgate Wiring

Technologies

CTA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CTA-2006 industry standards. These guidelines mean your amplifier’s output power ratings are REAL POWER numbers, not inflated marketing ratings.

Class-D

High efficiency amplifier design that reduces current consumption from the charging system.

Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

P.O.W.E.R.

Power supply circuit design that allows the amplifier to increase output power as voltage increases.

CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 EC).
