PMX-5CAN -Rockford Fosgate – Punch Marine AM/FM/WB Digital Media Receiver 2.7″ Display w/ CAN bus Source Unit Radio

PMX-5CAN -Rockford Fosgate – Punch Marine AM/FM/WB Digital Media Receiver 2.7″ Display w/ CAN bus Source Unit Radio

R13,476.30 inc. VAT

In stock

SKU: PMX-5CAN Categories: , , , , , , , Tag:

Description

The PMX-5CAN digital media receiver is designed for marine and motorsports systems.

The PMX-5CAN features a 2.7″full color TFT display for optimum viewing – even in full sun – that is optically wet bonded to prevent any dust or moisture penetration. It is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front mounted sub level controls. Additionally, with features such as SiriusXM and Pandora capabilities, Bluetooth audio steaming with album art support for Apple and Android products and true 2 zone/2 source control, this unit becomes a true command center of any system.

Output flexibility comes a 4x50W @ 2ohm internal amplifier or dual zone output RCA’s allowing the addition of after-market amplifiers for more power and output. Add in the EEPROM memory system, custom GUI interface and wired remote expansion capabilities and you have the only media receiver you’ll ever need. The PMX-5CAN also features CANbus functionality for connection to Raymarine MFD (Multi-Function Display) systems using the PMX-CAN adaptor (see Accessories tab.)

  • ISO8846/SAE J1171 Ignition Protection Certified
  • Stainless Steel Rear Chassis
  • Steering Wheel Control Interface Compatible
  • Pandora Internet Radio
  • SiriusXM-Ready™
  • A2DP and AVRCP Bluetooth Wireless Streaming
  • FCC, CE, IC, and C-Tick Certified
  • Multi Region Radio Frequencies
  • Low Voltage Warning Alert
  • AUX and USB Inputs with USB Charging
  • On Board Punch EQ Control
  • Independent Subwoofer Level Control
  • Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
  • IPX6 Marine Grade for prevention of water intrusion
  • 7-Band Graphic EQ
  • 2.7″ full color display w/ auto dimming backlightning
  • Zone Control: 2 Zone / 2 Source (F/R/S + F)
  • AM / FM / WB Tuner
  • CANbus (Controller Area Network) compatible. Requires PMX-CAN accessory
  • Compatible with a Multi-Funtion Display using NMEA2K entertainment standard. See our MFD Compatibility Chart
  • *Antenna not included
  • 2-Year Warranty

Additional information

Weight 2.13 kg
Dimensions 34 × 25 × 11 cm
Brand

Product Type

Overview

The PMX-5CAN digital media receiver is designed for marine and motorsports systems.

The PMX-5CAN features a 2.7″full color TFT display for optimum viewing – even in full sun – that is optically wet bonded to prevent any dust or moisture penetration. It is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front mounted sub level controls. Additionally, with features such as SiriusXM and Pandora capabilities, Bluetooth audio steaming with album art support for Apple and Android products and true 2 zone/2 source control, this unit becomes a true command center of any system.

Output flexibility comes a 4x50W @ 2ohm internal amplifier or dual zone output RCA’s allowing the addition of after-market amplifiers for more power and output. Add in the EEPROM memory system, custom GUI interface and wired remote expansion capabilities and you have the only media receiver you’ll ever need. The PMX-5CAN also features CAN-bus functionality for connection to NMEA 2000 systems using PMX-CAN adaptor (see Accessories tab.)

FEATURES AT A GLANCE

  • Pandora Internet Radio
  • SiriusXM-Ready™
  • Stainless Steel Rear Chassis
  • ISO8846/SAE J1171 Ignition Protection Certified
  • Low Voltage Warning Alert
  • AUX and USB Inputs with USB Charging
  • Multi-region radio frequencies
  • FCC, CE, IC, and C-Tick Certified
  • A2DP and AVRCP Bluetooth Wireless Streaming
  • Steering Wheel Control Interface Compatible
  • IPX6 Marine Grade for prevention of water intrusion
  • 7-Band Graphic EQ
  • 2.7″ full color display w/ auto dimming backlightning
  • Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
  • Independent Subwoofer Level Control
  • On Board Punch EQ Control
  • Zone Control: 2 Zone / 2 Source (F/R/S + F)
  • AM/FM/WB Tuner
  • Compatible with a Multi-Function Display using NMEA2K entertainment standard. See our MFD Compatibility Chart
  • CAN-bus (Controller Area Network) compatible. Requires PMX-CAN accessory
  • *Antenna not included
  • 2-Year Warranty

Specification

Display Size
2.7” Color TFT
Frequency Response
20 Hz – 20 kHz
Device Type
Digital-Media Receiver
Power Output
CEA-2006 Power Rating
25W x 4 @ 4Ω RMS
50W x 4 @ 2Ω Peak
≤1.0% THD+N
Operating Voltage
10.5 V – 16 V
FEATURES
Compatible Remotes
PMX-1R
PMX-0R
(3 Remote Limit, 100 ft Total Wired Distance)
Pandora® Internet Radio
(Yes/No)
Yes
SiriusXM-Ready®
(Yes/No)
Yes
Requires SXV300
Dimensions (HxWxD)
Width 8″ (20.3cm)
Face Depth 1.5″ (3.8cm)
Mount Depth 7.1″ (18.2cm)
Height 3.5″ (8.9cm)
Chassis to Face Top 0.9″ (2.3cm)
Chassis to Face Bottom 0.59″ (1.5cm)
Speaker Impedance
2-Ohms
Fuse Rating
15 A
Multi-Zone/Multi-Source
(Yes/No)
Yes
Speaker Outputs
(Yes/No)
Yes
Apple®/Android™ Compatible
(Yes/No)
Yes
TUNER
AUX Input
(Yes/No)
Yes
USB Charging
(Yes/No)
Yes
Clock
(Yes/No)
No
Steering Wheel Control Ready
(Yes/No)
Yes
FM TUNER
Frequency Range
87.9-107.9 MHz
TUNER
Number Of Presets
18 FM / 12 AM / 6 WB
FM TUNER
Sensitivity
8 dB
AM TUNER
Frequency Range
530 kHz – 1710 kHz
AM TUNER
Usable Sensitivity
40 dB
RCA OUTPUTS
WB TUNER
Frequency Range
162.40 – 162.55
(US & Canada)
RCA Output Voltage
4V
RCA Frequency Response
87.5 MHz – 107.9 MHz
RCA Output Impedance
500Ω
MEDIA PLAYER
Audio Format Compatibility
MP3
WMA
FLAC
MEDIA PLAYER
Made for iPod Models
iPod Touch (5th generation)
iPod Touch (4th generation)
iPod Nano (7th generation)
iPod Nano (6th generation)
Made for iPhone Models
iPhone XS (pending)
iPhone XS Max
iPhone XR (pending)
iPhone X
iPhone 8
iPhone 8 Plus
iPhone 7
iPhone 7 Plus
iPhone 6s
iPhone 6s Plus
iPhone 6
iPhone 6 Plus
iPhone 5S
iPhone 5C
iPhone 5
iPhone 4
iPhone 4S
Phone 3GS
USB Capacity
32Gb max
999 Folders max
999 Songs max
Android Compatibility
Bluetooth® Only
USB Output Current
1A
USB Version
2.0

Videos

Owner's Manual

PMX-5CAN.pdf Owners Manual
