P1S4-12 – Rockford Fosgate – Punch 12″ P1 4-Ohm SVC Subwoofer

R3,160.00 inc. VAT

In stock

Description

Rockford Fosgate P1 12″ are the first in a family of world famous subwoofers called “The Punch”. During their inception in the 1980’s, they quickly became “The Woofer of Choice” for fanatic car audio systems, with a continued tradition today. Kevlar fiber reinforced paper cones deliver bass impact you can feel, and our VAST technology in the Punch P1 woofer increases woofer surface cone area by up to 25%. Best in standard sealed and vented enclosures. Includes soft touch ABS tri trim ring.



  • Linear spider with embedded 16 AWG tinsel leads
  • High-temp voice coil with spun-laced Nomex® re-inforcement collar
  • Kevlar fiber reinforced paper cone
  • StampCast basket with integrated spider venting
  • Rubberized ABS trim ring with optional grille
  • Custom 10-AWG nickel plated push terminals
  • Extended pole piece and bumped vented back plate
  • Protective PVC textured magnet cover
  • 1 Year Warranty

Additional information

Weight 5.3 kg
Dimensions 37 × 37 × 22 cm
Brand

Product Type

Good, Better, Best

Power Rating

Size

Nominal Impedance

Subwoofer Depth

Overview

Rockford Fosgate P1 12″ are the first in a family of world famous subwoofers called “The Punch”. During their inception in the 1980’s, they quickly became “The Woofer of Choice” for fanatic car audio systems, with a continued tradition today. Kevlar fiber reinforced paper cones deliver bass impact you can feel, and our VAST technology in the Punch P1 woofer increases woofer surface cone area by up to 25%. Best in standard sealed and vented enclosures. Includes soft touch ABS trim ring.

FEATURES AT A GLANCE

  • Kevlar fiber reinforced paper cone
  • High-temp voice coil with spun-laced Nomex® re-inforcement collar
  • Linear spider with embedded 16 AWG tinsel leads
  • Custom 10-AWG nickel plated push terminals
  • StampCast basket with integrated spider venting
  • Rubberized ABS trim ring with optional grille
  • Extended pole piece and bumped vented backplate
  • 1 Year Warranty
  • Protective PVC textured magnet cover

Specification

ower Handling (Watts RMS)
250 Watts RMS
500 Watts Max
CEA-2031 Compliant
CEA-2031 Guidelines
Subwoofer Type
Standard
Size
12″
Nominal Impedance
4-Ohm
Magnet Weight (oz)
45 oz. (1.28 kg.)
Speaker Connector
Dual 10 AWG compression
Voice Coil Diameter
2.0″ (51.6 mm)
Voice Coil Type
Single Voice Coil
Le (mH)
3.01
Fs (Hz)
25
Qts
0.55
Qes
Xmax (mm)
9.0
Qms
3.40
Vas (Liters)
88.3
Re (Ohms)
3.6
Sd (cm2)
548
SPL (dB @ 1w/1m)
86
SPL (dB @ 2.8v/1m)
89
Cutout Diameter
11.22 in. (285 mm)
Mounting Depth
6.0 in. (152.4 mm)
Woofer Displacement
0.081 cu. ft. (2.3 Liters)
Sealed Box Volume (Vb)
1.02 cu. ft. (28.8 Liters)
Vented Box Volume (Vb)
1.79 cu. ft. (50.6 Liters)
0.56

Videos

Owners Manual

P1S4-12.pdf Owners Manual
