PS-8 – Rockford Fosgate – Punch Single 8″ Active Powered Subwoofer

R8,842.50 inc. VAT

Out of stock

Description

If you need to quickly add bass to a system but don’t have much space or height to make it happen? Then the PS-8 is a perfect candidate! The PS-8 features a Punch 8” subwoofer in a custom sealed enclosure and is powered by a mighty 150 Watt amplifier. The system is all-inclusive, so you only need to run power, ground and a signal from the source to get this baby moving. Features a durable exterior that resists scrapes and bumps while in the trunk or cargo area.

  • “Closed-loop” design ensures optimum performance between woofer, amplifier and enclosure
  • 150 Watt Class D Amplifier and 8″ Shallow Woofer
  • Adjustable 12db/Octave low pass crossover
  • Built-in adjustable bass boost EQ
  • Remote bass level control included
  • Hi-level/low-level inputs
  • Built-in 0°/180° phase switch
  • Remote/DC Offset/Signal Sense turn on select
  • Short circuit, thermal, and reverse polarity protection
  • Quick disconnect power and signal connections
  • Includes all power, ground, and turn-on wires
  • Includes mounting hardware
  • 1 Year Warranty

Additional information

Weight 6.5 kg
Dimensions 36.5 × 23.8 × 8.3 cm
Brand

Product Type

Good, Better, Best

Power Rating

Size

Enclosures

Powered

Overview

If you need to quickly add bass to a system but don’t have much space or height to make it happen? Then the PS-8 is a perfect candidate! The PS-8 features a Punch 8” subwoofer in a custom sealed enclosure and is powered by a mighty 150 Watt amplifier. The system is all-inclusive, so you only need to run power, ground and a signal from the source to get this baby moving. Features a durable exterior that resists scrapes and bumps while in the trunk or cargo area.

FEATURES AT A GLANCE

  • Built-in adjustable bass boost EQ
  • 150 Watt Class D Amplifier and 8″ Shallow Woofer
  • Remote bass level control included
  • “Closed-loop” design ensures optimum performance between woofer, amplifier and enclosure
  • Hi-level/low-level inputs
  • Adjustable 12db/Octave low pass crossover
  • Built-in 0°/180° phase switch
  • Quick disconnect power and signal connections
  • Short circuit, thermal, and reverse polarity protection
  • Remote/DC Offset/Signal Sense turn on select
  • Includes power, ground, and turn-on wires
  • 1 Year Warranty
  • Includes mounting hardware

Specification

CEA-2031 Compliant
CEA-2031 Guidelines
CEA-2006 Compliant
CEA-2006 Guidelines
Woofer Quantity
1
Woofer Series
Proprietary
Woofer Size
8″
Frequency Response
25 Hz to 150 Hz
Enclosure Type
Amplified
Enclosure Material
Cast aluminum w/ ABS backplate
Nominal Impedance (ea)
Integrated Amplifier
150 Watts RMS
Power Handling (Watts RMS)
150 Watts RMS
Speaker Connector
N/A
Crossover Controls
Variable 50 Hz to 120 Hz
12dB/Octave Butterworth
Tone Controls
Gain & Bass Boost
Signal Input
Low-Level: 1 RCA Pair
High-Level: Left/Right Summed Inputs
Power Input Connector
Removable Connector
Power/Ground/Remote
Replacement 1130-59232-01
Power Wire Gauge
Included
Remote Control
Included
Visual Indicators
Power
Protect
Heat Sink Type
Cast Aluminum
Cooling
Convection
Circuit Topology Class
Class-D

Owners Manual

PS-8.pdf Owners Manual
