P300-12 – Rockford Fosgate – Punch Single 12″ 300 Watt Active Powered Subwoofer

R9,999.00 inc. VAT

In stock

Description

If you need to quickly add bass to a system or want to alleviate the hassle of separate amplifiers and subwoofers, then the P300-12 is the right one for the job! The P300-12 features a Punch 12” subwoofer in a custom sealed enclosure and is powered by a mighty 300 Watt amplifier. The system is all-inclusive, so you only need to run power, ground and a signal from the source to get this baby moving. Features a durable exterior that resists scrapes and bumps while in the trunk or cargo area.

  • “Closed-loop” design ensures optimum performance between woofer, amplifier and enclosure
  • Built-in 0°/180° phase switch
  • Separate low level and speaker level inputs
  • Built-in adjustable bass boost EQ
  • Adjustable 12db/Octave low pass crossover
  • Detachable Power/Ground connector
  • Intelligent auto turn on/off function
  • Thermal and over/under voltage protection
  • High-efficiency, low current design
  • Remote bass level control included
  • Proprietary high output woofer
  • Constructed with 5/8″ MDF
  • Large AWG input terminals
  • Covered with industrial heat activated vinyl
  • 1 Year Warranty

Additional information

Weight 13.42 kg
Dimensions 50.29 × 38.1 × 27.94 cm
Brand

Product Type

Good, Better, Best

Power Rating

Size

Enclosures

Powered

Overview

If you need to quickly add bass to a system or want to alleviate the hassle of separate amplifiers and subwoofers, then the P300-12 is the right one for the job! The P300-12 features a Punch 12” subwoofer in a custom sealed enclosure and is powered by a mighty 300 Watt amplifier. The system is all-inclusive, so you only need to run power, ground and a signal from the source to get this baby moving. Features a durable exterior that resists scrapes and bumps while in the trunk or cargo area.

FEATURES AT A GLANCE

  • “Closed-loop” design ensures optimum performance between woofer, amplifier and enclosure
  • Separate low level and speaker level inputs
  • Built-in adjustable bass boost EQ
  • Built-in 0°/180° phase switch
  • Intelligent auto turn on/off function
  • Adjustable 12db/Octave low pass crossover
  • High-efficiency, low current design
  • Remote bass level control included
  • Proprietary high output woofer
  • Detachable Power/Ground connector
  • Thermal and over/under voltage protection
  • Large AWG input terminals
  • Covered with industrial heat activated vinyl
  • 1 Year Warranty
  • Constructed with 5/8″ MD

Specification

CEA-2031 Compliant
CEA-2031 Guidelines
CEA-2006 Compliant
CEA-2006 Guidelines
Woofer Quantity
1
Woofer Size
12″
Woofer Series
Proprietary
Frequency Response
20 Hz to 200 Hz
Nominal Impedance (ea)
Enclosure Material
5/8″ MDF (Medium Density Fiberboard)
Speaker Connector
n/a
Tone Controls
Gain & Bass Boost
Integrated Amplifier
300 Watts RMS
Signal Input
Low-Level: 1 RCA Pair
High-Level: Left/Right Summed Inputs
Cooling
Convection
Power Input Connector
Quick Disconnect
Replacement Part: 1130-59232-01
Remote Control
Included
Power Handling (Watts RMS)
300 Watts RMS
Enclosure Type
Amplified
Visual Indicators
Power
Protect
Crossover Controls
Variable 50 Hz to 200 Hz
12dB/Octave Butterworth
Shipping Weight
29.6 Lbs. (13.42 kg.)
Dimensions
Box (H x W x D)
Wedge (H x W x D1 x D2)
15 x 19.8 x D1 11 – D2 7 (in)
38.1 x 50.29 x D1 27.94 – D2 17.78 (cm)
Power Wire Gauge
8 AWG
Heat Sink Type
Extruded Aluminum
Circuit Topology Class
Class-D

Owners Manual

P300-12.pdf Owners Manual
