M2 12″ DVC 4Ω Color Optix™ Infinite Baffle Marine Subwoofer – Black

R12,879.00 inc. VAT

In stock

Description

The M2D4-12IB Color Optix™ 12” DVC 4-Ohm infinite baffle subwoofers deliver loud, clear, accurate bass, and light the way for your journey! Sold individually (1 each).

Color Optix™: Adjust your own bright, wide, and limitless lighting experience with the Rockford Fosgate Color Optix™ plug-and-play controller (sold separately) and App.

Element Ready™: Purpose Built for the Marine Environment, Rockford’s Element Ready™ products are built to stand up to Water, Salt, and UV rays, making sure your subwoofers stand the test of time.

Grille Customization: Multiple grille options provides a customized look by using either the stainless-steel grille or the “sport” grille inserts, allowing you to dial in your personalized-on water experience.

True Marine Ecosystem: Integrated Deutsch™ / Amphenol™ connections provide industry leading marine plug-and-play connectivity and flexible install options.

Color Optix™: Requires PMX-RGB controller and RF Connect™ App

Overview

The M2 series of Element Ready™ subwoofers are designed to pair with the Rockford Fosgate Color Optix™ Controller and RF Connect App through its Deutsch™ and Amphenol™ connectors integrated into the basket. This combined with their IP67 certification make these speakers Element Ready™ and truly purpose built for marine applications. To compliment the plug and play connectivity and streamline installation, M2 subwoofers are equipped with a VersaSwitch™ to make changing impedance between 2 and 8 ohms as easy as flipping a switch. This subwoofer is optimized for Infinite Baffle installations, where an enclosure is not required. A mounting baffle is required to isolate any interaction between the front and rear wavelengths to prevent cancellation.

Features

  • 2-Year Warranty
  • Injection molded mineral filled polypropylene cone body with UV inhibitors
  • VAST vertical attach surround technique increases effective radiating cone area up to 25%
  • Klippel Verified certification program delivers the best possible loudspeakers
  • Element Ready™ design protects lighting from exposure
  • Bright, wide-angle LEDs provide rich, reliable illumination
  • IPX6 Water Intrusion Rated
  • Gold plated marine grade brass terminals provide a corrosion resistant connection
  • Deutsch DT connectors incorporate front/rear silicone seals to protect against environmental ingress
  • Provides superb low and midrange frequency reproduction with smooth high frequency roll-off
  • Industry’s first molded in-frame connectors for simple connectivity in addition to conventional spade terminals
  • Integrated Deutsch™/Amphenol™ connectors make wiring connections simple and error proof
  • VERSA impedance switch quickly allows series or parallel configuration without additional wiring
  • Optimized for infinite baffle applications when an enclosure is not an option
  • Adjust color experience to suit your taste with Rockford Fosgate® Color Optix™ controller (optional)
  • 2-piece grille allows for interchangeable stainless-steel or “sport” option
  • 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment

Specification

Size
12″
Qes
1.14
Nominal Impedance (Ohms)
2-Ohm or 8-Ohm Switchable
Qts
0.94
Qms
5.27
Sd (cm2)
539
Le (mH)
3.43
Re (Ohms)
6.5
Fs (Hz)
38
Frequency Response (Hz)
20 Hz – 750 Hz
Magnet Weight (oz)
61.09 oz. (1.7 Kg)
Voice Coil Diameter
1.95″ (49.53 mm)
Power Handling (Watts RMS)
400 Watts RMS
1,600 Watts PEAK
Woofer Displacement
0.121 (3.43 Liters)
SPL (dB @ 1w/1m)
88
Vas
64.2
Voice Coil Type
Dual Voice Coil
Shipping Weight
14.26 Lbs. (6.47 Kg)
SPL (dB @ 2.8v)
90
Xmax (mm)
15
Speaker Connector
2-pin Deutsch™ and 1/8″ Spade
Cutout Diameter
11” (279.4 mm)
Mounting Depth
5.13″ (130.4 mm)
