M1-8 – Rockford Fosgate – White – Color Optix Marine 2-Way Speakers

R8,530.00 inc. VAT

Out of stock

Description

The M1-8 Color Optix™ 2-way 8” speakers deliver loud, clear, accurate sound, and light the way for your journey! The speakers connect with the Rockford Fosgate Color Optix™ Controller and RF Connect App, allowing you to customize your own color patterns. The Element Ready™ design and IPX6 certification makes them truly purpose-built for marine or motorsport applications where protection from damaging UV rays and water spray is essential.

Overview

The M1 series of Element Ready™ speakers are designed to pair with the Rockford Fosgate Color Optix™ Controller and RF Connect App through its Deutsch™ and Amphenol™ connectors integrated into the speaker. This combined with their IP67 certification make these speakers Element Ready™ and truly purpose built for marine applications. To complete your sound experience, the M1 speakers are complimented by 8-inch, 10-inch and 12-inch subwoofers, also controlled through the Color Optix™ lighting system.



FEATURES AT A GLANCE

  • Optically clear UV stable RGB Lighting Encapsulation
  • Multiplexed RGB Input
  • 1″ (25mm) High Temp Kapton™ Woofer Voice Coil Former
  • Grill Integrated 1″ (25 mm) LCP Balanced Dome Tweeter
  • Ultra-Bright, Wide Angle Tri-Color Surface Mount LED’s with Flat Mold Lenses
  • Linear Synthetic Fiber Blend Spiders
  • Co-molded surround and mineral filled polypropylene cone body
  • Zinc Nickel-plated Marine grade brass connection terminals
  • Sold in pairs (2 each)
  • VAST vertical attach surround technique increases effective radiating cone area up to 25%
  • Santoprene VAST Surround
  • 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment
  • Proprietary Dual Function Input Terminals
  • Sealed motor design
  • Integrated Deutsch RGB and Speaker receptacles
  • 2-Year Warranty
  • 6dB/Octave crossover network
  • Fully sealed integrated concealed crossover (ICC) network

Specifications

Speaker Type
2-way Coax
Tweeter Mounting Depth
Midrange Size (Nominal Diameter)
8″
Power Handling (RMS)
150 Watts RMS
600 Watts PEAK
Nominal Impedance (Ohms)
4-Ohm
Midrange Mounting Depth
3.3″ (83.9 mm)
Tweeter Size
1″ (25.4 mm)
Crossover
High Pass: 6dB/Octave
Sensitivity (dB @ 1W/1M)
92
Sensitivity (dB @ 2.83V/1M)
92
Frequency Response (Hz)
35 Hz – 22 kHz
Mounting Hardware
Stainless Steel
Grille/Trim Ring Included
Yes
Shipping Weight
9.25 Lbs. (4.20 Kg.)

Owners Manual

M1-8 – Owners Manual
