Harness – Rockford Fosgate – Replacement Power and Speaker Harnesses for PMX-HD9813
R2,384.24 inc. VAT
In stock
Description
Replacement harnesses to operate the PMX-HD9813 source unit. To be used for dealer displays or for installations where the factory Harley-Davidson® harnesses have been cut off or damaged beyond repair.
Additional information
| Weight | 1 kg |
|---|
Overview
The PMX-HD9813 source unit utilizes the factory wiring and therefore wiring harnesses are not supplied.
POWER
B+ (12v) Yellow
Switched (+12v) Red
Ground (-) Black
FRONT SPEAKERS
LEFT (+) White
LEFT (-) White/Black
RIGHT (+) Grey
RIGHT (-) Grey/Black
REAR SPEAKERS
LEFT (+) Green
LEFT (-) Green/Black
RIGHT (+) Purple
RIGHT (-) Purple/Black
See COMPATIBILITY chart to verify fitment before purchasing.
FEATURES AT A GLANCE
Sold in pairs (2 each)
Replacement harnesses for PMX-HD9813
Moisture-proof seals
Supplied with 23-pin harness (power & front speakers)
Supplied with 35-pin harness (rear speakers)
Harley-Davidson compatible connectors
Compatibility
Year Model Description
1998—2013 PMX-HD9813 Digital Media Receiver for 1998-2013 Harley-Davidson
